CITEL 3 PHASE+N TYPE 2+3 SPD IMAX 40KA 230/400V TN +VG

Stock Code: DS44VGS-230

Descriptions

• Type 2 AC Surge Protector

• In : 20 kA

• Imax : 40 kA

• Pluggable module for each phase

• Remote signaling option

• IEC 61643-11 and EN 61643-11 compliance

• UL1449 ed.4

Specifications

Type	Type 2 AC surge protector -Three Phase - Plugable
Number of Protected Poles	Three Phase + Neutral
Connection Mode	L/N or L/PE
Max. AC Operating Voltage	255VAC
Nominal Discharge Current - In	20kA
Max. Discharge Current - by pole Imax	40kA
Protection Level	1.25kV
Temporary Over Voltage (TOV) - 5 sec.	335VAC Withstand
Remote Signal	Yes
Network	230/400V

Downloads

Click on any of the following links to download the file.

DATASHEET (pdf)
