CITEL 1PHASE TYPE2 COMPACT SPD IMAX 40KA 230/400 TT-TN

Stock Code: DS240S-230/G

Descriptions

• Compact single-phase Type 2

• Ideal for Domestic Installations

• In : 20 kA

• Imax : 40 kA

• Pluggable module

• Remote signaling contact (option)

• Complies with EN 61643-11 and IEC 61643-11

• UL1449 ed.4

Specifications

Type	Compact Single Phase Type 2 surge protector
Number of Protected Poles	Single Phase
Connection Mode	L/N or L/PE
Max. AC Operating Voltage	255VAC
AC System	TT-TN
Nominal Discharge Current - In	20kA
Max. Discharge Current - by pole Imax	40kA
Protection Level	1.25kV
Temporary Over Voltage (TOV) - 5 sec.	335VAC Withstand
Remote Signal	Yes
Features	Configuration CT2 (common and differential mode)
Network	230V Single Phase

Downloads

Click on any of the following links to download the file.

Datasheet (pdf)
