| Approvals | IEC/EN 61643-11 cULus TUV EAC CE |
|---|---|
| Dimensions (mm) | L 260mm, W 160mm, D 110mm |
| Poles | 4 Pole |
| Materials (Body) | Metal Distribution Box |
| Ingress Protection | IP40 |
| Type | Type 1 + 2 AC Surge Protector |
| Connection Mode | L/n or L/PE |
| Max. AC Operating Voltage | 255VAC |
| Nominal Discharge Current - In | 20kA |
| Max. Discharge Current - by pole Imax | 50kA |
| Protection Level | 1.3kV |
| Temporary Over Voltage (TOV) - 5 sec. | 335VAC Withstand |
| Remote Signal | Yes |
| Features | High Energy MOV, Configuration CT2 (common and differential mode) |
There are no downloads for this product.
