| Approvals | UL / CSA / EAC / TUV |
|---|---|
| Amperage | 20A |
| Poles | 2 |
| Materials (Body) | Steel metal enclosure |
| Ingress Protection | IP20 |
| Voltage | 230V |
| Operating Temperature | -40 to +85℃ |
| Type | 2 |
| Number of Protected Poles | 2 |
| Nominal Discharge Current - In | 20 kA |
| Max. Discharge Current - by pole Imax | 40 kA |
| Temporary Over Voltage (TOV) - 5 sec. | 335VAC Withstand |
| Remote Signal | Optional |
| Features | 1 Mechanical indicator |
| Network | TT/TN |
| Max VAC | 255Vac |
| Cable Capacity | 1.5mm-10mm (L/N) or 2.5mm-25mm(PE) |
There are no downloads for this product.
