Standard Coil

Standard Coil

  • 10A switching capability
  • 1 Form A configuration
  • High inrush current TV-8 118A
  • Wash tight
  • TV-5 125VAC approved by UL standards (Form A only)
  • Contact material AgSnO2
  • RoHS compliant
  • Safety approval UL/CUL & TUV



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF36FD005HT HONGFA PCB POWER RELAY 5VDC 10A 1NO HF36F/005-HT 1A - Single Pole Normally Open 5VDC 530mW 6.5 10AMP 3.75 0.25 47 x (1�10%)
HF36FD006HT HONGFA PCB POWER RELAY 6VDC 10A 1NO HF36F/006-HT 1A - Single Pole Normally Open 6VDC 530mW 7.8 10AMP 4.5 0.3 68 x (1�10%)
HF36FD009HT HONGFA PCB POWER RELAY 9VDC 10A 1NO HF36F/009-HT 1A - Single Pole Normally Open 9VDC 530mW 11.7 10AMP 6.75 0.45 155 x (1�10%)
HF36FD012HT HONGFA PCB POWER RELAY 12VDC 10A 1NO HF36F/012-HT 1A - Single Pole Normally Open 12VDC 530mW 15.6 10AMP 9 0.6 270 x (1�10%)
HF36FD018HT HONGFA PCB POWER RELAY 18VDC 10A 1NO HF36F/018-HT 1A - Single Pole Normally Open 18VDC 530mW 23.4 10AMP 13.5 0.9 620 x (1�10%)
HF36FD024HT HONGFA PCB POWER RELAY 24VDC 10A 1NO HF36F/024-HT 1A - Single Pole Normally Open 24VDC 530mW 31.2 10AMP 18 1.2 1080 x (1�10%)
HF36FD048HT HONGFA PCB POWER RELAY 48VDC 10A 1NO HF36F/048-HT 1A - Single Pole Normally Open 48VDC 530mW 62.4 10AMP 36 2.4 4400 x (1�10%)
