Standard Coil - 450mW

Standard Coil - 450mW

  • 10A switching capacity
  • 1 Form C configuration
  • Subminiature PCB layout
  • Standard coil version
  • Contact material AgCdO
  • RoHS compliant
  • Class F insulation as standard



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF8-1C003DEF HONGFA PCB CUBE RELAY 3VDC 2A 1CO HF8-1C003-DEF 1C - Sinle Pole Changeover 3VDC 450mW 3.9 2AMP 2.25 0.15 20 x (1�10%)
HF8-1C005DEF HONGFA PCB CUBE RELAY 5VDC 2A 1CO HF8-1C005-DEF 1C - Sinle Pole Changeover 5VDC 450mW 6.5 2AMP 3.75 0.25 56 x (1�10%)
HF8-1C006DEF HONGFA PCB CUBE RELAY 6VDC 2A 1CO HF8-1C006-DEF 1C - Sinle Pole Changeover 6VDC 450mW 7.8 2AMP 4.5 0.3 80 x (1�10%)
HF8-1C009DEF HONGFA PCB CUBE RELAY 9VDC 2A 1CO HF8-1C009-DEF 1C - Sinle Pole Changeover 9VDC 450mW 11.7 2AMP 6.75 0.45 180 x (1�10%)
HF8-1C012DEF HONGFA PCB CUBE RELAY 12VDC 2A 1CO HF8-1C012-DEF 1C - Sinle Pole Changeover 12VDC 450mW 15.6 2AMP 9 0.6 320 x (1�10%)
HF8-1C018DEF HONGFA PCB CUBE RELAY 18VDC 2A 1CO HF8-1C018-DEF 1C - Sinle Pole Changeover 18VDC 450mW 23.4 2AMP 13.5 0.9 720 x (1�10%)
HF8-1C024DEF HONGFA PCB CUBE RELAY 24VDC 2A 1CO HF8-1C024-DEF 1C - Sinle Pole Changeover 24VDC 450mW 31.2 2AMP 18 1.2 1280 x (1�10%)
HF8-1C048DEF HONGFA PCB CUBE RELAY 48VDC 2A 1CO HF8-1C048-DEF 1C - Sinle Pole Changeover 48VDC 450mW 62.4 2AMP 36 2.4 3800 x (1�10%)
