Standard Coil - 450mW

Standard Coil - 450mW

  • 10A switching capacity
  • 1 Form A configuration
  • Subminiature PCB layout
  • Standard coi l version
  • Contact material AgCdO
  • RoHS compliant
  • Class F insulation as standard



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF8-1AH003DEF HONGFA PCB CUBE RELAY 3VDC 6A 1NO HF8-1AH003-DEF 1A - Single Pole Normally Open 3VDC 450mW 3.9 6AMP 2.25 0.15 20 x (1�10%)
HF8-1AH005DEF HONGFA PCB CUBE RELAY 5VDC 6A 1NO HF8-1AH005-DEF 1A - Single Pole Normally Open 5VDC 450mW 6.5 6AMP 3.75 0.25 56 x (1�10%)
HF8-1AH006DEF HONGFA PCB CUBE RELAY 6VDC 6A 1NO HF8-1AH006-DEF 1A - Single Pole Normally Open 6VDC 450mW 7.8 6AMP 4.5 0.3 80 x (1�10%)
HF8-1AH009DEF HONGFA PCB CUBE RELAY 9VDC 6A 1NO HF8-1AH009-DEF 1A - Single Pole Normally Open 9VDC 450mW 11.7 6AMP 6.75 0.45 180 x (1�10%)
HF8-1AH012DEF HONGFA PCB CUBE RELAY 12VDC 6A 1NO HF8-1AH012-DEF 1A - Single Pole Normally Open 12VDC 450mW 15.6 6AMP 9 0.6 320 x (1�10%)
HF8-1AH018DEF HONGFA PCB CUBE RELAY 18VDC 6A 1NO HF8-1AH018-DEF 1A - Single Pole Normally Open 18VDC 450mW 23.4 6AMP 13.5 0.9 720 x (1�10%)
HF8-1AH024DEF HONGFA PCB CUBE RELAY 24VDC 6A 1NO HF8-1AH024-DEF 1A - Single Pole Normally Open 24VDC 450mW 31.2 6AMP 18 1.2 1280 x (1�10%)
HF8-1AH048DEF HONGFA PCB CUBE RELAY 48VDC 6A 1NO HF8-1AH048-DEF 1A - Single Pole Normally Open 48VDC 450mW 62.4 6AMP 36 2.4 3800 x (1�10%)
