Sensitive Coil - 330mW

Sensitive Coil - 330mW

  • 10A switching capacity
  • 1 Form A configuration
  • Subminiature PCB layout
  • Sensitive coil version
  • Contact material AgCdO
  • RoHS compliant
  • Class F insulation as standard



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF8-1AH003DSEF HONGFA PCB CUBE RELAY 3VDC 6A 1NO HF8-1AH003-DSEF 1A - Single Pole Normally Open 3VDC 330mW 3.9 6AMP 2.25 0.15 28 x (1�10%)
HF8-1AH005DSEF HONGFA PCB CUBE RELAY 5VDC 6A 1NO HF8-1AH005-DSEF 1A - Single Pole Normally Open 5VDC 330mW 6.5 6AMP 3.75 0.25 80 x (1�10%)
HF8-1AH006DSEF HONGFA PCB CUBE RELAY 6VDC 6A 1NO HF8-1AH006-DSEF 1A - Single Pole Normally Open 6VDC 330mW 7.8 6AMP 4.5 0.3 110 x (1�10%)
HF8-1AH009DSEF HONGFA PCB CUBE RELAY 9VDC 6A 1NO HF8-1AH009-DSEF 1A - Single Pole Normally Open 9VDC 330mW 11.7 6AMP 6.75 0.45 250 x (1�10%)
HF8-1AH012DSEF HONGFA PCB CUBE RELAY 12VDC 6A 1NO HF8-1AH012-DSEF 1A - Single Pole Normally Open 12VDC 330mW 15.6 6AMP 9 0.6 440 x (1�10%)
HF8-1AH018DSEF HONGFA PCB CUBE RELAY 18VDC 6A 1NO HF8-1AH018-DSEF 1A - Single Pole Normally Open 18VDC 330mW 23.4 6AMP 13.5 0.9 1000 x (1�10%)
HF8-1AH024DSEF HONGFA PCB CUBE RELAY 24VDC 6A 1NO HF8-1AH024-DSEF 1A - Single Pole Normally Open 24VDC 330mW 31.2 6AMP 18 1.2 1780 x (1�10%)
HF8-1AH048DSEF HONGFA PCB CUBE RELAY 48VDC 6A 1NO HF8-1AH048-DSEF 1A - Single Pole Normally Open 48VDC 330mW 62.4 6AMP 36 2.4 7120 x (1�10%)
