16 Amp Single Pole

16 Amp Single Pole

  • Change Over Contacts
  • Supplied complete, Relay, LED, Socket, Ejector Clip and Identification Label
  • 1 Part Number for simple ordering
  • AC & DC Coils
  • Supply status LED as standard
  • 35mm Din Rail mounting
  • 2 Socket types for ease of installation
  • 16A version
  • Other Coil Voltages available on request



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Coil Voltage Retainer Clip Module Type Maximum Rated Switching Current Additional Features Socket Type Relay Voltage Relay Type Contact Arrangement Operating Temperature Cable Size, Solid (mm2) Cable Size, Flexible (mm2) Dimensions (mm) Approvals Price
1RM-110A-16A-3 HONGFA RELAY INTERFACE MODULE 1CO 110VAC 110VAC 14F-ERC-1 HF-EN 16AMP Contact Separation Socket 14FF-2Z-C3 110VAC HF115FA1151ZS3AF 1C - Single Pole Changeover -40 to +85℃ 1 x 4/ 2 x 2.5 1 x 4/ 2 x 2.5 65 x 76 x 15.8 CE, UL
1RM-12-16A-3 HONGFA RELAY INTERFACE MODULE 1CO 12VDC 12VDC 14F-ERC-1 HF-EL 16AMP Contact Separation Socket 14FF-2Z-C3 12VDC HF115F0121ZS3AF 1C - Single Pole Changeover -40 to +85℃ 1 x 4/ 2 x 2.5 1 x 4/ 2 x 2.5 65 x 76 x 15.8 CE, UL
1RM-230A-16A-3 HONGFA RELAY INTERFACE MODULE 1CO 230VAC 230VAC 14F-ERC-1 HF-EN 16AMP Contact Separation Socket 14FF-2Z-C3 230VAC HF115FA2301ZS3AF 1C - Single Pole Changeover -40 to +85℃ 1 x 4/ 2 x 2.5 1 x 4/ 2 x 2.5 65 x 76 x 15.8 CE, UL
1RM-24-16A-3 HONGFA RELAY INTERFACE MODULE 1CO 24VDC 24VDC 14F-ERC-1 HF-EL 16AMP Contact Separation Socket 14FF-2Z-C3 24VDC HF115F0241ZS3AF 1C - Single Pole Changeover -40 to +85℃ 1 x 4/ 2 x 2.5 1 x 4/ 2 x 2.5 65 x 76 x 15.8 CE, UL
1RM-24A-16A-3 HONGFA RELAY INTERFACE MODULE 1CO 24VAC 24VAC 14F-ERC-1 HF-EL 16AMP Contact Separation Socket 14FF-2Z-C3 24VAC HF115FA0241ZS3AF 1C - Single Pole Changeover -40 to +85℃ 1 x 4/ 2 x 2.5 1 x 4/ 2 x 2.5 65 x 76 x 15.8 CE, UL
