Single Coil Latching

Single Coil Latching



    • 200A 277VAC/28VDC contact ratings



    • 2 Form B contacts



    • 1 Coil latching version



    • H eavy load up to 55.4kVA



    • Contact material AgSn02In203. Contacts in AgCdO available upon request



    • 4Kvdielectric strength between coil and contacts



    • RoHS compliant



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Maximum Rated Switching Current Pick Up Max VDC Coil ? � 10% Set/Reset Voltage VDC Max Pulse Duration ms min. Price
HFE6A0122DT1 HONGFA LATCHING RELAY 12VDC 200A 2NC HFE6-A/012-2DT1 2B - Single Pole Normally Closed 12VDC 12W 200AMP 9.6 12 x (1�10%) 200 150
HFE6A0242DT1 HONGFA LATCHING RELAY 24VDC 200A 2Nc HFE6-A/024-2DT1 2B - Single Pole Normally Closed 24VDC 12W 200AMP 19.2 48 x (1�10%) 200 150
HFE6A0482DT1 HONGFA LATCHING RELAY 48VDC 200A 2Nc HFE6-A/048-2DT1 2B - Single Pole Normally Closed 48VDC 12W 200AMP 38.4 190 x (1�10%) 200 150
