Double Coil Latching

Double Coil Latching



    • 60A switching capability



    • Accordance with IEC 62055:UC3



    • Contact: 3000A; Bearable load 6000A Load Inrush



    • 2 Coil Latching



    • 1 Form A contact



    • Reverse polarity available



    • 4Kvdielectric strength between coil and contacts



    • RoHS compliant



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Maximum Rated Switching Current Pick Up Max VDC Coil ? � 10% Pulse Duration ms min. Price
HFE1960005HT42 HONGFA LATCHING RELAY 5VDC 60A NO HFE19-90/005-HT-42 1A - Single Pole Normally Open 5VDC 2000mW 60AMP 3.5 12 + 12 x (1�10%) 100
HFE1960006HT42 HONGFA LATCHING RELAY 6VDC 60A NO HFE19-90/006-HT-42 1A - Single Pole Normally Open 6VDC 2000mW 60AMP 4.2 17.5 + 17.5 x (1�10%) 100
HFE1960009HT42 HONGFA LATCHING RELAY 9VDC 60A NO HFE19-90/009-HT-42 1A - Single Pole Normally Open 9VDC 2000mW 60AMP 6.3 40 + 40 x (1�10%) 100
HFE1960012HT42 HONGFA LATCHING RELAY 12VDC 60A NO HFE19-90/012-HT-42 1A - Single Pole Normally Open 12VDC 2000mW 60AMP 8.4 72 + 72 x (1�10%) 100
HFE1960024HT42 HONGFA LATCHING RELAY 24VDC 60A NO HFE19-90/024-HT-42 1A - Single Pole Normally Open 24VDC 2000mW 60AMP 19.2 285 + 285 x (1�10%) 100
HFE1960048HT42 HONGFA LATCHING RELAY 48VDC 60A NO HFE19-90/048-HT-42 1A - Single Pole Normally Open 48VDC 2000mW 60AMP 38.4 1135 + 1135 x (1�10%) 100
