Positive Polarity

Positive Polarity

No detailed description is available for this product.

No detailed specifications are available for this product.

Click on any of the following links to download the file.

Code Description Contact Arrangement Coil Voltage Coil Power Maximum Rated Switching Current Coil ? � 10% Set/Reset Voltage VDC Max Pulse Duration ms min. Price
HFE10L006HTL1 HONGFA LATCHING RELAY 6VDC 60A PCB HFE10-L/006-HTL1 1A - Sinle Pole Normally Open 6VDC 1.5W 60AMP 22 x (1�10%) 4.8 50
HFE10L009HTL1 HONGFA LATCHING RELAY 9VDC 60A PCB HFE10-L/009-HTL1 1A - Sinle Pole Normally Open 9VDC 1.5W 60AMP 54 x (1�10%) 7.2 50
HFE10L012HTL1 HONGFA LATCHING RELAY 12VDC 60A PCB HFE10-L/012-HTL1 1A - Sinle Pole Normally Open 12VDC 1.5W 60AMP 100 x (1�10%) 9.6 50
HFE10L015HTL1 HONGFA LATCHING RELAY 15VDC 60A PCB HFE10-L/015-HTL1 1A - Sinle Pole Normally Open 15VDC 1.5W 60AMP 150 x (1�10%) 12 50
HFE10L024HTL1 HONGFA LATCHING RELAY 24VDC 60A PCB HFE10-L/024-HTL1 1A - Sinle Pole Normally Open 24VDC 1.5W 60AMP 360 x (1�10%) 19.2 50
HFE10L048HTL1 HONGFA LATCHING RELAY 48VDC 60A PCB HFE10-L/048-HTL1 1A - Sinle Pole Normally Open 48VDC 1.5W 60AMP 1600 x (1�10%) 38.4 50
