VDC

VDC

  • 16 Amp switching capacity
  • 1 Form A contact
  • 2.5KV dielectric strength (between coil and contacts)
  • Panel types available
  • RoHS compliant
  • Approvals UL

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF84F4D006 HONGFA INDUSTRIAL RELAY 6VDC 16A 1NO HF84F-4D006 1A - Single Pole Normally Open 6VDC 2100mW 6.6 16 AMP 4.5 0.6 17.5 x (1�10%)
HF84F4D009 HONGFA INDUSTRIAL RELAY 9VDC 16A 1NO HF84F-4D009 1A - Single Pole Normally Open 9VDC 2100mW 9.9 16 AMP 6.75 0.9 40 x (1�10%)
HF84F4D012 HONGFA INDUSTRIAL RELAY 12VDC 16A 1NO HF84F-4D012 1A - Single Pole Normally Open 12VDC 2100mW 13.2 16 AMP 9 1.2 70 x (1�10%)
HF84F4D024 HONGFA INDUSTRIAL RELAY 24VDC 16A 1NO HF84F-4D024 1A - Single Pole Normally Open 24VDC 2100mW 26.4 16 AMP 18 2.4 280 x (1�10%)
HF84F4D048 HONGFA INDUSTRIAL RELAY 48VDC 16A 1NO HF84F-4D048 1A - Single Pole Normally Open 48VDC 2100mW 52.8 16 AMP 36 4.8 1120 x (1�10%)
HF84F4D120 HONGFA INDUSTRIAL RELAY 120VDC 16A 1NO HF84F-4D120 1A - Single Pole Normally Open 120VDC 2100mW 132 16 AMP 90 12 7000 x (1�10%)
