VAC

VAC

  • 16 Amp switching capacity
  • 1 Form A contact
  • 2.5KV dielectric strength (between coil and contacts)
  • Panel types available
  • RoHS compliant
  • Approvals UL




No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VAC Maximum Rated Switching Current Coil ? � 10% Pick Up Max VAC Drop Out Max VAC Price
HF84F4A006 HONGFA INDUSTRIAL RELAY 6VAC 16A 1NO HF84F-4A006 1A - Single Pole Normally Open 6VAC 3.5VA 6.6 16 AMP 4.8 x (1�10%) 5.1 1.2
HF84F4A012 HONGFA INDUSTRIAL RELAY 12VAC 16A 1NO HF84F-4A012 1A - Single Pole Normally Open 12VAC 3.5VA 13.2 16 AMP 19 x (1�10%) 10.2 2.4
HF84F4A024 HONGFA INDUSTRIAL RELAY 24VAC 16A 1NO HF84F-4A024 1A - Single Pole Normally Open 24VAC 3.5VA 26.4 16 AMP 90 x (1�10%) 20.4 4.8
HF84F4A048 HONGFA INDUSTRIAL RELAY 48VAC 16A 1NO HF84F-4A048 1A - Single Pole Normally Open 48VAC 3.5VA 52.8 16 AMP 300 x (1�10%) 40.6 9.6
HF84F4A120 HONGFA INDUSTRIAL RELAY 120VAC 16A 1NO HF84F-4A120 1A - Single Pole Normally Open 120VAC 3.5VA 132 16 AMP 2000 x (1�10%) 102 24
HF84F4A240 HONGFA INDUSTRIAL RELAY 240VAC 16A 1NO HF84F-4A240 1A - Single Pole Normally Open 240VAC 3.5VA 264 16 AMP 7200 x (1�10%) 204 48
HF84F4A277 HONGFA INDUSTRIAL RELAY 277VAC 16A 1NO HF84F-4A277 1A - Single Pole Normally Open 277VAC 3.5VA 304.7 16 AMP 11000 x (1�10%) 235 55.4
