15 Amp 1 Pole Normally Closed - 1 Form B

15 Amp 1 Pole Normally Closed - 1 Form B

  • 15 Amp switching capacity
  • 900mW Coil
  • 1 Form B contact
  • PCB Coil terminals, suitable for heavy duty load
  • Heavy load up to 7200VA
  • Plastic sealed and Flux proofed types available
  • Class F Insulation available
  • RoHS compliant
  • Approvals UL and CQC



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF2150-1B005DEF HONGFA PCB POWER RELAY 5VDC 15A 1NC HF2150-1B-005DEF 1B - Single Pole Normally Closed 5VDC 900mW 6.5 15 AMP 3.75 0.5 27 x (1�10%)
HF2150-1B006DEF HONGFA PCB POWER RELAY 6VDC 15A 1NC HF2150-1B-006DEF 1B - Single Pole Normally Closed 6VDC 900mW 7.8 15 AMP 4.5 0.6 40 x (1�10%)
HF2150-1B009DEF HONGFA PCB POWER RELAY 9VDC 15A 1NC HF2150-1B-009DEF 1B - Single Pole Normally Closed 9VDC 900mW 11.7 15 AMP 6.75 0.9 97 x (1�10%)
HF2150-1B012DEF HONGFA PCB POWER RELAY 12VDC 15A 1NC HF2150-1B-012DEF 1B - Single Pole Normally Closed 12VDC 900mW 15.6 15 AMP 9 1.2 155 x (1�10%)
HF2150-1B015DEF HONGFA PCB POWER RELAY 15VDC 15A 1NC HF2150-1B-015DEF 1B - Single Pole Normally Closed 15VDC 900mW 19.5 15 AMP 11.25 1.5 256 x (1�10%)
HF2150-1B018DEF HONGFA PCB POWER RELAY 18VDC 15A 1NC HF2150-1B-018DEF 1B - Single Pole Normally Closed 18VDC 900mW 23.4 15 AMP 13.5 1.8 380 x (1�10%)
HF2150-1B024DEF HONGFA PCB POWER RELAY 24VDC 15A 1NC HF2150-1B-024DEF 1B - Single Pole Normally Closed 24VDC 900mW 31.2 15 AMP 18 2.4 660 x (1�10%)
HF2150-1B048DEF HONGFA PCB POWER RELAY 48VDC 15A 1NC HF2150-1B-048DEF 1B - Single Pole Normally Closed 48VDC 900mW 62.4 15 AMP 36 4.8 2560 x (1�10%)
HF2150-1B070DEF HONGFA PCB POWER RELAY 70VDC 15A 1NC HF2150-1B-070DEF 1B - Single Pole Normally Closed 70VDC 900mW 91 15 AMP 52.5 7 5500 x (1�10%)
HF2150-1B110DEF HONGFA PCB POWER RELAY 110VDC 15A 1NC HF2150-1B-110DEF 1B - Single Pole Normally Closed 110VDC 900mW 143 15 AMP 82.5 11 13450 x (1�10%)
