20 Amp 1 Pole Changeover Relay

20 Amp 1 Pole Changeover Relay

  • 20 Amp switching capacity
  • 1 Form C contact
  • PCB Coil terminals, suitable for heavy duty load
  • 2.5KV dielectric strength (between coil and contacts)
  • Plastic sealed and Flux proofed types available
  • Class F Insulation available
  • RoHS compliant
  • Approvals UL, CQC and TUV



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF21001C005DEF HONGFA PCB POWER RELAY 5VDC 20A 1CO HF2100-1C-005DEF 1C - Single Pole Changeover 5VDC 900mW 6.5 20 AMP 3.75 0.5 27 x (1�10%)
HF21001C006DEF HONGFA PCB POWER RELAY 6VDC 20A 1CO HF2100-1C-006DEF 1C - Single Pole Changeover 6VDC 900mW 7.8 20 AMP 4.5 0.6 40 x (1�10%)
HF21001C009DEF HONGFA PCB POWER RELAY 9VDC 20A 1CO HF2100-1C-009DEF 1C - Single Pole Changeover 9VDC 900mW 11.7 20 AMP 6.75 0.9 97 x (1�10%)
HF21001C012DEF HONGFA PCB POWER RELAY 12VDC 20A 1CO HF2100-1C-012DEF 1C - Single Pole Changeover 12VDC 900mW 15.6 20 AMP 9 1.2 155 x (1�10%)
HF21001C015DEF HONGFA PCB POWER RELAY 15VDC 20A 1CO HF2100-1C-015DEF 1C - Single Pole Changeover 15VDC 900mW 19.5 20 AMP 11.25 1.5 256 x (1�10%)
HF21001C018DEF HONGFA PCB POWER RELAY 18VDC 20A 1CO HF2100-1C-018DEF 1C - Single Pole Changeover 18VDC 900mW 23.4 20 AMP 13.5 1.8 380 x (1�10%)
HF21001C024DEF HONGFA PCB POWER RELAY 24VDC 20A 1CO HF2100-1C-024DEF 1C - Single Pole Changeover 24VDC 900mW 31.2 20 AMP 18 2.4 660 x (1�10%)
HF21001C048DEF HONGFA PCB POWER RELAY 48VDC 20A 1CO HF2100-1C-048DEF 1C - Single Pole Changeover 48VDC 900mW 62.4 20 AMP 36 4.8 2560 x (1�10%)
HF21001C070DEF HONGFA PCB POWER RELAY 70VDC 20A 1CO HF2100-1C-070DEF 1C - Single Pole Changeover 70VDC 900mW 91 20 AMP 52.5 7 5500 x (1�10%)
HF21001C110DEF HONGFA PCB POWER RELAY 110VDC 20A 1CO HF2100-1C-110DEF 1C - Single Pole Changeover 110VDC 900mW 143 20 AMP 82.5 11 13450 x (1�10%)
