High Dielectric Strength (4000VAC Between Coil & Contacts)

High Dielectric Strength (4000VAC Between Coil & Contacts)

No detailed description is available for this product.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF165FD005DY1STFV HONGFA PCB POWER RELAY 5VDC 30A 1NC HF165FD/005-DY1STFV 1B - Single Pole Normally Closed 5VDC 900mW 6.5 30AMP 3.75 0.5 27 x (1�10%)
HF165FD006DY1STFV HONGFA PCB POWER RELAY 6VDC 30A 1NC HF165FD/006-DY1STFV 1B - Single Pole Normally Closed 6VDC 900mW 7.8 30AMP 4.5 0.6 40 x (1�10%)
HF165FD009DY1STFV HONGFA PCB POWER RELAY 9VDC 30A 1NC HF165FD/009-DY1STFV 1B - Single Pole Normally Closed 9VDC 900mW 11.7 30AMP 6.75 0.9 97 x (1�10%)
HF165FD012DY1STFV HONGFA PCB POWER RELAY 12VDC 30A 1NC HF165FD/012-DY1STFV 1B - Single Pole Normally Closed 12VDC 900mW 15.6 30AMP 9 1.2 155 x (1�10%)
HF165FD015DY1STFV HONGFA PCB POWER RELAY 15VDC 30A 1NC HF165FD/015-DY1STFV 1B - Single Pole Normally Closed 15VDC 900mW 19.5 30AMP 11.25 1.5 256 x (1�10%)
HF165FD018DY1STFV HONGFA PCB POWER RELAY 18VDC 30A 1NC HF165FD/018-DY1STFV 1B - Single Pole Normally Closed 18VDC 900mW 23.4 30AMP 13.5 1.8 380 x (1�10%)
HF165FD024DY1STFV HONGFA PCB POWER RELAY 24VDC 30A 1NC HF165FD/024-DY1STFV 1B - Single Pole Normally Closed 24VDC 900mW 31.2 30AMP 18 2.4 660 x (1�10%)
HF165FD048DY1STFV HONGFA PCB POWER RELAY 48VDC 30A 1NC HF165FD/048-DY1STFV 1B - Single Pole Normally Closed 48VDC 900mW 62.4 30AMP 36 4.8 2560 x (1�10%)
HF165FD110DY1STFV HONGFA PCB POWER RELAY 110VDC 30A 1NC HF165FD/110-DY1STFV 1B - Single Pole Normally Closed 48VDC 900mW 143 30AMP 82.5 11 13450 x (1�10%)
