20 Amp 1 Pole Normally Open Relay

20 Amp 1 Pole Normally Open Relay

  • 20 Amp switching capacity
  • 5KV dielectric strength (between coil and contacts)
  • 1 Form A contact
  • 400mW Coil
  • Creepage distance 10mm
  • Class F Insulation
  • Relays compliant with IEC 60335-1 also available
  • Plastic sealed and Flux proofed types available
  • RoHS compliant
  • Approvals VDE & UL



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF158F005HS3T HONGFA PCB POWER RELAY 5VDC 20A 1NO HF158F/005-HS3T 1A - Single Pole Normally Open 5VDC 400mW 9 20 AMP 3.5 0.5 62 x (1�10%)
HF158F006HS3T HONGFA PCB POWER RELAY 6VDC 20A 1NO HF158F/006-HS3T 1A - Single Pole Normally Open 6VDC 400mW 10.8 20 AMP 4.2 0.6 90 x (1�10%)
HF158F009HS3T HONGFA PCB POWER RELAY 9VDC 20A 1NO HF158F/009-HS3T 1A - Single Pole Normally Open 9VDC 400mW 16.2 20 AMP 6.3 0.9 202 x (1�10%)
HF158F012HS3T HONGFA PCB POWER RELAY 12VDC 20A 1NO HF158F/012-HS3T 1A - Single Pole Normally Open 12VDC 400mW 21.6 20 AMP 8.4 1.2 360 x (1�10%)
HF158F018HS3T HONGFA PCB POWER RELAY 18VDC 20A 1NO HF158F/018-HS3T 1A - Single Pole Normally Open 18VDC 400mW 32.4 20 AMP 12.6 1.8 810 x (1�10%)
HF158F024HS3T HONGFA PCB POWER RELAY 24VDC 20A 1NO HF158F/024-HS3T 1A - Single Pole Normally Open 24VDC 400mW 43.2 20 AMP 16.8 2.4 1440 x (1�10%)
HF158F048HS3T HONGFA PCB POWER RELAY 48VDC 20A 1NO HF158F/048-HS3T 1A - Single Pole Normally Open 48VDC 400mW 86.4 20 AMP 33.6 4.8 5760 x (1�15%)
