VAC

VAC

  • 30 Amp switching capacity
  • 1 Form A contact
  • Heavy load up to 7200VA
  • 4KV dielectricstrength (between coil and contacts)
  • 3mm contact gap
  • Contact materials AgSnO2
  • Available on request AgCdO
  • RoHS compliant
  • PCB and Flangless types also available on request
  • Approvals UL, TUV and CUL
  • Class F Insulation



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VAC Maximum Rated Switching Current Pick Up Max VAC Price
HF116F1006AF1HTFW HONGFA INDUSTRIAL RELAY 6VAC 30A 1NO HF116F-1/006AF-1HTFW 1A - Single Pole Normally Open 6VAC 2.7VA 6.6 30 AMP 4.8
HF116F1012AF1HTFW HONGFA INDUSTRIAL RELAY 12VAC 30A 1NO HF116F-1/012AF-1HTFW 1A - Single Pole Normally Open 12VAC 2.7VA 13.2 30 AMP 9.6
HF116F1024AF1HTFW HONGFA INDUSTRIAL RELAY 24VAC 30A 1NO HF116F-1/024AF-1HTFW 1A - Single Pole Normally Open 24VAC 2.7VA 26.4 30 AMP 19.2
HF116F1048AF1HTFW HONGFA INDUSTRIAL RELAY 48VAC 30A 1NO HF116F-1/048AF-1HTFW 1A - Single Pole Normally Open 48VAC 2.7VA 52.8 30 AMP 38.4
HF116F1120AF1HTFW HONGFA INDUSTRIAL RELAY 120AC 30A 1NO HF116F-1/120AF-1HTFW 1A - Single Pole Normally Open 120VAC 2.7VA 132 30 AMP 96
HF116F1220AF1HTFW HONGFA INDUSTRIAL RELAY 220AC 30A 1NO HF116F-1/220AF-1HTFW 1A - Single Pole Normally Open 220VAC 2.7VA 242 30 AMP 176
HF116F1230AF1HTFW HONGFA INDUSTRIAL RELAY 230VAC 30A 1NO HF116F-1/230AF-1HTFW 1A - Single Pole Normally Open 230VAC 2.7VA 253 30A 276
