16 Amp Normally Closed 5mm Pinning - 1 Form B

16 Amp Normally Closed 5mm Pinning - 1 Form B

  • 16 amp switching capacity
  • 400mW rated coil
  • 5KV dielectric strength (between coil & contacts)
  • 1 Form B contact
  • Creepage distance 10mm
  • DC coil version
  • Contact Material AgSnO2 as standard
  • Available on request AgCdO, AgNi, AgCdO + Au plated and AgNi + Au plated contacts
  • RoHS Complaint
  • Fully sealed as standard
  • Compliant with VDE 0435/0631/0700
  • Approvals FIMKO,VDE, UL & CUL
  • P.C. & DIN rail sockets available
  • Insulation Class F



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF115F0051DS3AF HONGFA PCB POWER RELAY 5DC 16A 1NC HF115F/005-1DS3AF 1B - Single Pole Normally Closed 5VDC 400mW 7.5 16 AMP 3.5 0.5 62 x (1�10%)
HF115F0061DS3AF HONGFA PCB POWER RELAY 6DC 16A 1NC HF115F/006-1DS3AF 1B - Single Pole Normally Closed 6VDC 400mW 9 16 AMP 4.2 0.6 90 x (1�10%)
HF115F0091DS3AF HONGFA PCB POWER RELAY 9DC 16A 1NC HF115F/009-1DS3AF 1B - Single Pole Normally Closed 9VDC 400mW 13.5 16 AMP 6.3 0.9 202 x (1�10%)
HF115F0121DS3AF HONGFA PCB POWER RELAY 12DC 16A 1NC HF115F/012-1DS3AF 1B - Single Pole Normally Closed 12VDC 400mW 18 16 AMP 8.4 1.2 360 x (1�10%)
HF115F0181DS3AF HONGFA PCB POWER RELAY 18DC 16A 1NC HF115F/018-1DS3AF 1B - Single Pole Normally Closed 18VDC 400mW 27 16 AMP 12.6 1.8 810 x (1�10%)
HF115F0241DS3AF HONGFA PCB POWER RELAY 24DC 16A 1NC HF115F/024-1DS3AF 1B - Single Pole Normally Closed 24VDC 400mW 36 16 AMP 16.8 2.4 1440 x (1�15%)
HF115F0481DS3AF HONGFA PCB POWER RELAY 48DC 16A 1NC HF115F/048-1DS3AF 1B - Single Pole Normally Closed 48VDC 400mW 72 16 AMP 33.6 4.8 5760 x (1�15%)
HF115F0601DS3AF HONGFA PCB POWER RELAY 60DC 16A 1NC HF115F/060-1DS3AF 1B - Single Pole Normally Closed 60VDC 400mW 90 16 AMP 42 6 7500 x (1�15%)
HF115F1101DS3AF HONGFA PCB POWER RELAY 110DC 16A 1NC HF115F/110-1DS3AF 1B - Single Pole Normally Closed 110VDC 400mW 165 16 AMP 77 11 25200 x (1�10%)
