30 Amp 1 Pole Normally Open Relay AC Coils

30 Amp 1 Pole Normally Open Relay AC Coils

  • 30 Amp switching capacity
  • AC Coil
  • 1 Form A contact
  • Heavy load up to 7200VA
  • Wash tight
  • 4KV dielectric strength (between coil and contacts)
  • Contact materials AgSnO2
  • RoHS compliant
  • PCB Coil terminals, suitable for heavy duty loads
  • Approvals UL, CUL and TUV
  • 6.4QC (Faston) power connection



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VAC Maximum Rated Switching Current Coil ? � 10% Pick Up Max VAC Drop Out Max VAC Price
HF105F5012A1HSTF HONGFA PCB POWER RELAY 12VAC 1NO HF105F5/012A-1HSTF(136) 1A- Single Pole Normally Open 12VAC 2VA 15.6 20 AMP 25 x (1�10%) 9.6 2.4
HF105F5024A1HSTF HONGFA PCB POWER RELAY 24VAC 1NO HF105F5/024A-1HSTF(136) 1A- Single Pole Normally Open 24VAC 2VA 31.2 20 AMP 100 x (1�10%) 19.2 4.8
HF105F5120A1HSTF HONGFA PCB POWER RELAY 120VAC 1NO HF105F5/120A-1HSTF(136) 1A- Single Pole Normally Open 120VAC 2VA 156 20 AMP 2500 x (1�10%) 96 24
HF105F5208A1HSTF HONGFA PCB POWER RELAY 208VAC 1NO HF105F5/208A-1HSTF(136) 1A- Single Pole Normally Open 208VAC 2VA 270.4 20 AMP 11000 x (1�10%) 166.4 41
HF105F5220A1HSTF HONGFA PCB POWER RELAY 220VAC 1NO HF105F5/220A-1HSTF(136) 1A- Single Pole Normally Open 220VAC 2VA 286 20 AMP 13490 x (1�10%) 176 44
HF105F5240A1HSTF HONGFA PCB POWER RELAY 240VAC 1NO HF105F5/240A-1HSTF(136) 1A- Single Pole Normally Open 240VAC 2VA 286 20 AMP 13490 x (1�10%) 192 48
HF105F5277A1HSTF HONGFA PCB POWER RELAY 277VAC 1NO HF105F5/0277A-1HSTF(136) 1A- Single Pole Normally Open 277VAC 2VA 360.1 20 AMP 15000 x (1�10%) 220 54
