8 Amp 2 Pole Changeover - 2 Form C

8 Amp 2 Pole Changeover - 2 Form C

  • 8 Amp switching capacity
  • Manual Test Button, Flag & LED indication
  • 5KV dielectric strength (between coil & contacts)
  • DC coil
  • Contact Material AgNi
  • RoHS Compliant
  • Compliant with VDE 0435/0631/0700
  • Approvals UL, CUR & VDE
  • PC & DIN Rail Plug In sockets available



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Maximum Rated Switching Current Coil ? � 10% Price
HF115FP0122Z4B HONGFA PCB POWER RELAY 12VDC 8A 2CO HF115FP/012-2Z4B 2C - Double Pole Changeover 12VDC 400mW 8 AMP 360 x (1�10%)
HF115FP0242Z4B HONGFA PCB POWER RELAY 24VDC 8A 2CO HF115FP/024-2Z4B 2C - Double Pole Changeover 24VDC 400mW 8 AMP 1440 x (1�10%)
HF115FP0482Z4B HONGFA PCB POWER RELAY 48VDC 8A 2CO HF115FP/048-2Z4B 2C - Double Pole Changeover 48VDC 400mW 8 AMP 5760 x (1�15%)
HF115FP1102Z4B HONGFA PCB POWER RELAY 110VDC 8A 2CO HF115FP/110-2Z4B 2C - Double Pole Changeover 110VDC 400mW 8 AMP 25200 x (1�15%)
HF115FPA0242Z4B HONGFA PCB POWER RELAY 24VAC 8A 2CO HF115FP/A024-2Z4B 2C - Double Pole Changeover 24VAC 0.75VA 8 AMP 350 x (1�10%)
HF115FPA1152Z4B HONGFA PCB POWER RELAY 110VAC 8A 2CO HF115FP/A115-2Z4B 2C - Double Pole Changeover 110VAC 0.75VA 8 AMP 8100 x (1�10%)
HF115FPA2302Z4B HONGFA PCB POWER RELAY 230VAC 8A 2CO HF115FP/A230-2Z4B 2C - Double Pole Changeover 230VAC 0.75VA 8 AMP 32500 x (1�15%)
