VDC

VDC

  • 8 Amp switching capacity
  • 1 Form C contact
  • 2.5KV dielectric strength (between coil and contacts)
  • Panel types available
  • RoHS compliant
  • Approvals UL



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF84F1D006 HONGFA INDUSTRIAL RELAY 6VDC 8A 1CO HF84F-1D006 1C - Single Pole Changeover 6VDC 2100mW 6.6 8 AMP 4.5 0.6 17.5 x (1�10%)
HF84F1D009 HONGFA INDUSTRIAL RELAY 9VDC 8A 1CO HF84F-1D009 1C - Single Pole Changeover 9VDC 2100mW 9.9 8 AMP 6.75 0.9 40 x (1�10%)
HF84F1D012 HONGFA INDUSTRIAL RELAY 12VDC 8A 1CO HF84F-1D012 1C - Single Pole Changeover 12VDC 2100mW 13.2 8 AMP 9 1.2 70 x (1�10%)
HF84F1D024 HONGFA INDUSTRIAL RELAY 24VDC 8A 1CO HF84F-1D024 1C - Single Pole Changeover 24VDC 2100mW 26.4 8 AMP 18 2.4 280 x (1�10%)
HF84F1D048 HONGFA INDUSTRIAL RELAY 48VDC 8A 1CO HF84F-1D048 1C - Single Pole Changeover 48VDC 2100mW 52.8 8 AMP 36 4.8 1120 x (1�10%)
HF84F1D120 HONGFA INDUSTRIAL RELAY 120VDC 8A 1CO HF84F-1D120 1C - Single Pole Changeover 120VDC 2100mW 132 8 AMP 90 12 7000 x (1�10%)
