VAC

VAC

  • 8 Amp switching capacity
  • 1 Form C contact
  • 2.5KV dielectric strength (between coil and contacts)
  • Panel types available
  • RoHS compliant
  • Approvals UL



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VAC Maximum Rated Switching Current Coil ? � 10% Pick Up Max VAC Drop Out Max VAC Price
HF84F1A006 HONGFA INDUSTRIAL RELAY 6VAC 8A 1CO HF84F-1A006 1C - Single Pole Changeover 6VAC 3.5VA 6.6 8 AMP 4.8 x (1�10%) 5.1 1.2
HF84F1A012 HONGFA INDUSTRIAL RELAY 12VAC 8A 1CO HF84F-1A012 1C - Single Pole Changeover 12VAC 3.5VA 13.2 8 AMP 19 x (1�10%) 10.2 2.4
HF84F1A024 HONGFA INDUSTRIAL RELAY 24VAC 8A 1CO HF84F-1A024 1C - Single Pole Changeover 24VAC 3.5VA 26.4 8 AMP 90 x (1�10%) 20.4 4.8
HF84F1A048 HONGFA INDUSTRIAL RELAY 48VAC 8A 1CO HF84F-1A048 1C - Single Pole Changeover 48VAC 3.5VA 52.8 8 AMP 300 x (1�10%) 40.6 9.6
HF84F1A120 HONGFA INDUSTRIAL RELAY 120VAC 8A 1CO HF84F-1A120 1C - Single Pole Changeover 120VAC 3.5VA 132 8 AMP 2000 x (1�10%) 102 24
HF84F1A240 HONGFA INDUSTRIAL RELAY 240VAC 8A 1CO HF84F-1A240 1C - Single Pole Changeover 240VAC 3.5VA 264 8 AMP 7200 x (1�10%) 204 48
HF84F1A277 HONGFA INDUSTRIAL RELAY 277VAC 8A 1CO HF84F-1A277 1C - Single Pole Changeover 277VAC 3.5VA 304.7 8 AMP 11000 x (1�10%) 235 55.4
