5mm Pin 12 Amp

5mm Pin 12 Amp

No detailed description is available for this product.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF115FK005Z2T HONGFA PCB POWER RELAY 5VDC 12A 1CO HF115F-K/005-Z1T 1C - Single Pole Changeover 5VDC 400mW 7.5 12AMP 3.5 0.5 62 x (1�10%)
HF115FK006Z2T HONGFA PCB POWER RELAY 6VDC 12A 1CO HF115F-K/006-Z1T 1C - Single Pole Changeover 6VDC 400mW 9 12AMP 4.2 0.6 90 x (1�10%)
HF115FK009Z2T HONGFA PCB POWER RELAY 9VDC 12A 1CO HF115F-K/009-Z1T 1C - Single Pole Changeover 9VDC 400mW 13.5 12AMP 6.3 0.9 202 x (1�10%)
HF115FK012Z2T HONGFA PCB POWER RELAY 12VDC 12A 1CO HF115F-K/012-Z1T 1C - Single Pole Changeover 12VDC 400mW 18 12AMP 8.4 1.2 360 x (1�10%)
HF115FK018Z2T HONGFA PCB POWER RELAY 18VDC 12A 1CO HF115F-K/018-Z1T 1C - Single Pole Changeover 18VDC 400mW 27 12AMP 12.6 1.8 810 x (1�10%)
HF115FK024Z2T HONGFA PCB POWER RELAY 24VDC 12A 1CO HF115F-K/024-Z1T 1C - Single Pole Changeover 24VDC 400mW 36 12AMP 16.8 2.4 1400 x (1�10%)
HF115FK048Z2T HONGFA PCB POWER RELAY 48VDC 12A 1CO HF115F-K/048-Z1T 1C - Single Pole Changeover 48VDC 400mW 72 12AMP 33.6 4.8 5760 x (1�10%)
