26 Amp 1 Pole Normally Open Relay

26 Amp 1 Pole Normally Open Relay

  • 26 Amp switching capacity
  • 1 Form A contact
  • 1.4W Coil
  • 1.5mm contact gap
  • Creepage distance <8mm
  • Clearance distance between contact and coil <6.4mm
  • Low coil holding voltage contributes to energy saving
  • RoHS compliant
  • Approvals UL, VDE and CQC



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF161FW009HT HONGFA PCB POWER RELAY 9VDC 26A 1NO HF161F-W/009-HT 1A - Single Pole Normally Open 9VDC 1400mW 10.8 26 AMP 6.3 0.9 58 x (1�10%)
HF161FW012HT HONGFA PCB POWER RELAY 12VDC 26A 1NO HF161F-W/012-HT 1A - Single Pole Normally Open 12VDC 1400mW 14.4 26 AMP 8.4 1.2 103 x (1�10%)
HF161FW018HT HONGFA PCB POWER RELAY 18VDC 26A 1NO HF161F-W/018-HT 1A - Single Pole Normally Open 18VDC 1400mW 21.6 26 AMP 12.6 1.8 230 x (1�10%)
HF161FW024HT HONGFA PCB POWER RELAY 24VDC 26A 1NO HF161F-W/024-HT 1A - Single Pole Normally Open 24VDC 1400mW 28.8 26 AMP 16.8 2.4 410 x (1�10%)
