VDC

VDC

  • 18 Amp switching capacity
  • 2.4W Coil
  • 2KV dielectric strength (between coil and contacts)
  • Class F insulation
  • RoHS compliant
  • Approvals UL



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF94F13D006 HONGFA INDUSTRIAL RELAY 6VDC 18A 1NO+NC HF94F-13D006 1A + 1B - Single pole Normally Open + Normally Closed 6VDC 2400mW 6.6 18 AMP 4.5 0.6 17.5 x (1�10%)
HF94F13D009 HONGFA INDUSTRIAL RELAY 9VDC 18A 1NO+NC HF94F-13D009 1A + 1B - Single pole Normally Open + Normally Closed 9VDC 2400mW 9.9 18 AMP 6.75 0.9 40 x (1�10%)
HF94F13D012 HONGFA INDUSTRIAL RELAY 12DC 18A 1NO+NC HF94F-13D012 1A + 1B - Single pole Normally Open + Normally Closed 12VDC 2400mW 13.2 18 AMP 9 1.2 70 x (1�10%)
HF94F13D024 HONGFA INDUSTRIAL RELAY 24DC 18A 1NO+NC HF94F-13D024 1A + 1B - Single pole Normally Open + Normally Closed 24VDC 2400mW 26.4 18 AMP 18 2.4 280 x (1�10%)
HF94F13D048 HONGFA INDUSTRIAL RELAY 48DC 18A 1NO+NC HF94F-13D048 1A + 1B - Single pole Normally Open + Normally Closed 48VDC 2400mW 52.8 18 AMP 36 4.8 1120 x (1�10%)
HF94F13D120 HONGFA INDUSTRIAL RELAY 120VDC 18A 1NO+NC HF94F-13D120 1A + 1B - Single pole Normally Open + Normally Closed 120VDC 2400mW 132 18 AMP 90 12 7000 x (1�10%)
