VDC

VDC

  • 18 Amp switching capacity
  • 2.4W Coil
  • 2KV dielectric strength (between coil and contacts)
  • Class F insulation
  • RoHS compliant
  • Approvals UL



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF94F12D006 HONGFA INDUSTRIAL RELAY 6VDC 18A 1CO HF94F-12D006 1C - Single Pole Changeover 6VDC 2400mW 6.6 18 AMP 4.5 0.6 17.5 x (1�10%)
HF94F12D009 HONGFA INDUSTRIAL RELAY 9VDC 18A 1CO HF94F-12D009 1C - Single Pole Changeover 9VDC 2400mW 9.9 18 AMP 6.75 0.9 40 x (1�10%)
HF94F12D012 HONGFA INDUSTRIAL RELAY 12DC 18A 1CO HF94F-12D012 1C - Single Pole Changeover 12VDC 2400mW 13.2 18 AMP 9 1.2 70 x (1�10%)
HF94F12D024 HONGFA INDUSTRIAL RELAY 24DC 18A 1CO HF94F-12D024 1C - Single Pole Changeover 24VDC 2400mW 26.4 18 AMP 18 2.4 280 x (1�10%)
HF94F12D048 HONGFA INDUSTRIAL RELAY 48DC 18A 1CO HF94F-12D048 1C - Single Pole Changeover 48VDC 2400mW 52.8 18 AMP 36 4.8 1120 x (1�10%)
HF94F12D120 HONGFA INDUSTRIAL RELAY 120VDC 18A 1CO HF94F-12D120 1C - Single Pole Changeover 120VDC 2400mW 132 18 AMP 90 12 7000 x (1�10%)
