  • 18 Amp switching capacity
  • 4.0VA Coil
  • 2KV dielectric strength (between coil and contacts)
  • Class F insulation
  • RoHS compliant
  • Approvals UL





No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VAC Maximum Rated Switching Current Coil ? � 10% Pick Up Max VAC Drop Out Max VAC Price
HF94F12A006 HONGFA INDUSTRIAL RELAY 6VAC 18A 1CO HF94F-12A006 1C - Single Pole Changeover 6VAC 4.0VA 6.6 18 AMP 4.8 x (1�10%) 5.1 1.2
HF94F12A012 HONGFA INDUSTRIAL RELAY 12AC 18A 1CO HF94F-12A012 1C - Single Pole Changeover 12VAC 4.0VA 13.2 18 AMP 19 x (1�10%) 10.2 2.4
HF94F12A024 HONGFA INDUSTRIAL RELAY 24AC 18A 1CO HF94F-12A024 1C - Single Pole Changeover 24VAC 4.0VA 26.4 18 AMP 77 x (1�10%) 20.4 4.8
HF94F12A048 HONGFA INDUSTRIAL RELAY 48AC 18A 1CO HF94F-12A048 1C - Single Pole Changeover 48VAC 4.0VA 52.8 18 AMP 280 x (1�10%) 40.8 9.6
HF94F12A120 HONGFA INDUSTRIAL RELAY 120VAC 18A 1CO HF94F-12A120 1C - Single Pole Changeover 120VAC 4.0VA 132 18 AMP 2000 x (1�10%) 102 24
HF94F12A240 HONGFA INDUSTRIAL RELAY 240VAC 18A 1CO HF94F-12A240 1C - Single Pole Changeover 240VAC 4.0VA 264 18 AMP 7250 x (1�10%) 204 48
HF94F12A277 HONGFA INDUSTRIAL RELAY 277VAC 18A 1CO HF94F-12A277 1C - Single Pole Changeover 277VAC 4.0VA 304.7 18 AMP 11000 x (1�10%) 235 55.4
