VAC

VAC

  • 18 Amp switching capacity
  • 4.0VA Coil
  • 2KV dielectric strength (between coil and contacts)
  • Class F insulation
  • RoHS compliant
  • Approvals UL



No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VAC Maximum Rated Switching Current Coil ? � 10% Pick Up Max VAC Drop Out Max VAC Price
HF94F12A0061 HONGFA INDUSTRIAL RELAY 6VAC 18A 1CO HF94F-12A006-1 1C - Single Pole Changeover 6VAC 4.0VA 6.6 18 AMP 4.8 x (1�10%) 5.1 1.2
HF94F12A0121 HONGFA INDUSTRIAL RELAY 12AC 18A 1CO HF94F-12A012-1 1C - Single Pole Changeover 12VAC 4.0VA 13.2 18 AMP 19 x (1�10%) 10.2 2.4
HF94F12A0241 HONGFA INDUSTRIAL RELAY 24AC 18A 1CO HF94F-12A024-1 1C - Single Pole Changeover 24VAC 4.0VA 26.4 18 AMP 77 x (1�10%) 20.4 4.8
HF94F12A0481 HONGFA INDUSTRIAL RELAY 48AC 18A 1CO HF94F-12A048-1 1C - Single Pole Changeover 48VAC 4.0VA 52.8 18 AMP 280 x (1�10%) 40.8 9.6
HF94F12A1201 HONGFA INDUSTRIAL RELAY 120VAC 18A 1CO HF94F-12A120-1 1C - Single Pole Changeover 120VAC 4.0VA 132 18 AMP 2000 x (1�10%) 102 24
HF94F12A2401 HONGFA INDUSTRIAL RELAY 240VAC 18A 1CO HF94F-12A240-1 1C - Single Pole Changeover 240VAC 4.0VA 264 18 AMP 7250 x (1�10%) 204 48
HF94F12A2771 HONGFA INDUSTRIAL RELAY 277VAC 18A 1CO HF94F-12A277-1 1C - Single Pole Changeover 277VAC 4.0VA 304.7 18 AMP 11000 x (1�10%) 235 55.4
