  • 16 Amp switching capacity
  • 1 Form B contact
  • 2.5KV dielectric strength (between coil and contacts)
  • Panel types available
  • RoHS compliant
  • Approvals UL

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VDC Maximum Rated Switching Current Pick Up Max VDC Drop Out Max VDC Coil ? � 10% Price
HF84F7D006 HONGFA INDUSTRIAL RELAY 6VDC 16A 1NC HF84F-7D006 1B - Single Pole Normally Closed 6VDC 2100mW 6.6 16 AMP 4.5 0.6 17.5 x (1�10%)
HF84F7D009 HONGFA INDUSTRIAL RELAY 9VDC 16A 1NC HF84F-7D009 1B - Single Pole Normally Closed 9VDC 2100mW 9.9 16 AMP 6.75 0.9 40 x (1�10%)
HF84F7D012 HONGFA INDUSTRIAL RELAY 12VDC 16A 1NC HF84F-7D012 1B - Single Pole Normally Closed 12VDC 2100mW 13.2 16 AMP 9 1.2 70 x (1�10%)
HF84F7D024 HONGFA INDUSTRIAL RELAY 24VDC 16A 1NC HF84F-7D024 1B - Single Pole Normally Closed 24VDC 2100mW 26.4 16 AMP 18 2.4 280 x (1�10%)
HF84F7D048 HONGFA INDUSTRIAL RELAY 48VDC 16A 1NC HF84F-7D048 1B - Single Pole Normally Closed 48VDC 2100mW 52.8 16 AMP 36 4.8 1120 x (1�10%)
HF84F7D120 HONGFA INDUSTRIAL RELAY 120VDC 16A 1NC HF84F-7D120 1B - Single Pole Normally Closed 120VDC 2100mW 132 16 AMP 90 12 7000 x (1�10%)
