VAC

VAC

  • 16 Amp switching capacity
  • 1 Form B contact
  • 2.5KV dielectric strength (between coil and contacts)
  • Panel types available
  • RoHS compliant
  • Approvals UL

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Contact Arrangement Coil Voltage Coil Power Max VAC Maximum Rated Switching Current Coil ? � 10% Pick Up Max VAC Drop Out Max VAC Price
HF84F7A006 HONGFA INDUSTRIAL RELAY 6VAC 16A 1NC HF84F-7A006 1B - Single Pole Normally Closed 6VAC 3.5VA 6.6 16 AMP 4.8 x (1�10%) 5.1 1.2
HF84F7A012 HONGFA INDUSTRIAL RELAY 12VAC 16A 1NC HF84F-7A012 1B - Single Pole Normally Closed 12VAC 3.5VA 13.2 16 AMP 19 x (1�10%) 10.2 2.4
HF84F7A024 HONGFA INDUSTRIAL RELAY 24VAC 16A 1NC HF84F-7A024 1B - Single Pole Normally Closed 24VAC 3.5VA 26.4 16 AMP 90 x (1�10%) 20.4 4.8
HF84F7A048 HONGFA INDUSTRIAL RELAY 48VAC 16A 1NC HF84F-7A048 1B - Single Pole Normally Closed 48VAC 3.5VA 52.8 16 AMP 300 x (1�10%) 40.6 9.6
HF84F7A120 HONGFA INDUSTRIAL RELAY 120VAC 16A 1NC HF84F-7A120 1B - Single Pole Normally Closed 120VAC 3.5VA 132 16 AMP 2000 x (1�10%) 102 24
HF84F7A240 HONGFA INDUSTRIAL RELAY 240VAC 16A 1NC HF84F-7A240 1B - Single Pole Normally Closed 240VAC 3.5VA 264 16 AMP 7200 x (1�10%) 204 48
HF84F7A277 HONGFA INDUSTRIAL RELAY 277VAC 16A 1NC HF84F-7A277 1B - Single Pole Normally Closed 277VAC 3.5VA 304.7 16 AMP 11000 x (1�10%) 235 55.4
