Vertical Male 10mm Pitch Plug In Terminal Blocks Closed End

Vertical Male 10mm Pitch Plug In Terminal Blocks Closed End

• 10mm Plug in connectors
• 2-12 pole solid block
• Pluggable male connectors
• Closed headers
• Vertical male plugs
• Polarised mouldings
• Moulded in green UL94-V0 flame retardant PA
• Guided pin alignment
• IMQ, VDE, UL approved
• Alternative colours available upon request

No detailed specifications are available for this product.

Click on any of the following links to download the file.

Code Description Colour Amperage Poles Voltage Pitch Operating Temperature Price
PV02-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 2 POLE Green 15 AMPS 2 500V 10mm -40 to +130℃
PV03-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 3 POLE Green 15 AMPS 3 500V 10mm -40 to +130℃
PV04-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 4 POLE Green 15 AMPS 4 500V 10mm -40 to +130℃
PV05-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 5 POLE Green 15 AMPS 5 500V 10mm -40 to +130℃
PV06-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 6 POLE Green 15 AMPS 6 500V 10mm -40 to +130℃
PV07-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 7 POLE Green 15 AMPS 7 500V 10mm -40 to +130℃
PV08-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 8 POLE Green 15 AMPS 8 500V 10mm -40 to +130℃
PV09-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 9 POLE Green 15 AMPS 9 500V 10mm -40 to +130℃
PV10-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 10 POLE Green 15 AMPS 10 500V 10mm -40 to +130℃
PV11-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 11 POLE Green 15 AMPS 11 500V 10mm -40 to +130℃
PV12-10.00-V-P EUROCLAMP PCB CLOSED HEADER VERTICAL 16A 10mm 12 POLE Green 15 AMPS 12 500V 10mm -40 to +130℃
